Description
Crank it up or keep it clean. The DSL40C gives you the flexibility to find your perfect tone. With a variety of EQ settings to choose from, you can take this combo from the studio to the stage with confidence.
PLAY ANYWHERE
Match your sound to your environment and switch between full power and half power.
SWITCH UP YOUR SOUND
Craft your perfect sound with presence, resonance and tone shift controls. With individual reverb settings per channel and an FX loop, the DSL40C gives you more sonic control.
DIAL IN YOUR TONE
Each channel comes with two modes for a bigger range of tonal possibilities.
TECHNICAL SPECIFICATION
GENERAL
Technology : Valve
Channels : 2 (Split)
ELECTRONICS
Output wattage : 40W
Outputs : Speaker outputs: 3 x 1/4" jack sockets (16Ω load / 8Ω load)
Inputs : 1 x 1/4" instrument input jack
Controls : Classic gain channel: Gain level, Clean/crunch select, Volume, Channel select, Ultra gain channel: Gain level, Lead 1 / Lead 2 button, Volume, Treble, Middle, Bass, Tone shift, Presence control, Resonance control, Reverb (classic gain channel), Reverb (ultra gain channel), Pentode/triode power reduction switch (on rear)
Effects : Reverb
Effects loop : Yes, Send/Return with bypass switch
SPEAKERS
Speaker configuration : 1x12"
Speaker model : Celestion Seventy 80 G12P-80 (80W, 16Ω)
Unit impedance : 16Ω
VALVES
Pre amp valves : 4 x ECC83
Power amp valves : 2 x EL34
ACCESSORIES
Footswitch : Originally shipped with PEDL-00009 which was replaced by PEDL-91004
Cable : Detachable power cable included, Speaker cable included
